Heavy-duty head with additionally induction hardened cutting edges (approx. 64 HRC). Laid-on joint. High cutting performance due to optimum leverage.
Jaws bright finished, plastic coated handles.
For all types of wire (long working life even with hard wire). Heavy duty for the most demanding applications.
Standard: DIN ISO 5749
Material: Chrome vanadium steel, drop-forged and oil-hardened.
Cutting capacity piano wire up to ⌀2,5 mm
Cutting capacity soft wire up to ⌀4,2mm
overall length: 200 mm
Cutting capacity hard wire up to ⌀3 mm

For connecting screwdriver bits to drive attachments or screwdrivers with a 1/4, 3/8 or 1/2 inch square drive.
With quick-change coupling; for electric screwdrivers.
Square drive: 1/4 inch
overall length: 30 mm
Hexagon drive: C 6.3 (1/4 inch)

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 10 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 8 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 6 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 5 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 4 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Single piece, i.e. shank and tip of one piece. Shanks for direct fitting in electric screwdrivers.
Application:
For hexagon socket head screws DIN 7426.
Standard: DIN ISO 1173
Material: Of PB Swiss Tools special steel combining maximum hardness with exceptional toughness.
Drive profile: Hexagon screwdriver
Hexagon: 3 mm
overall length: 50 mm
Bit hexagon shank: E6.3

Kraftform handle for easy transmission of the required torque. With Rapidaptor quick-change holder for 1/4 inch bits with C6.3 and E6.3 shank. Sizes 600 and 880 with pistol grip for transmission of higher torques.
The torque can be set using a torque analyser (No. 654300 − 654460) and a 7AF hexagon screwdriver (10AF for size 600) . The torque screwdrivers are factory-set to the most frequently used torque setting.
When the set torque is reached the screwdriver triggers, with clearly audible and perceptible signals. The triggering torque is unrestricted.
maximum torque: 120 cN·m
set torque: 0.3 N·m
Bit socket: D6.3 ; F6.3
Torque range:0.3 N·m - 1.2 N·m
Connection format: bitholder 1/4 tomme
Overall length L: 155 mm
Adjustable trigger value: pre-set

Comfortable multi-material cross handle made of plastic. Chrome-vanadium steel blade, chrome-plated.
Hexagonal: 6mm
Blade length: 350 mm
Total length: 382 mm

In plastic clip.
L-form shaft to DIN 911/DIN ISO 2936, chromium-vanadium steel, end faces squared and milled.
Content table use: 1 pc. each screwdriver Size 2; 2.5; 3; 4; 5; 6; 8

Special steel drive head ground, hardened and burnished; with fixed pins.
Application: For twin hole nuts.
Note: Pin ⌀ = pin nominal ⌀ - 0.1 mm; tolerance field h12.
Pin spacing adjustable: 7 mm - 40 mm
overall length: 115 mm

Sturdy design with chamfered arms, tool steel, forged and precision ground. Riveted through joint hinge. Hardened and ground points.

Sturdy design with chamfered arms, tool steel, forged and precision ground. Riveted through joint hinge. Hardened and ground points.

1 straight point; knurled metal handle.
overall length: 180 mm

Solid semicircular graduated arc with graduation 0 − 180°; reading 1°.
Scale plate non-glare chrome-plated. With clamping nut.

Carbide measuring surfaces finely lapped.
Measuring pin hardened and ground.
Blocking by lever.
With friction clutch and insulation.
With graduation of quality.
Metrology: Analogue / Packaging: Robust box / Standard: DIN 863 / ⌀ Spindle: 6.5 mm / Reading: 0.01 mm / Calibration: B1 / Measuring range: 0 mm - 25 mm / Micrometer scale: 1/50 mm / ⌀ micrometer drum: 18 mm

All faces and edges ground. Inspection test faces ground.
Application:
For accurate general workshop work.
Accuracy:
DIN 875 / 2 − angle tolerance e.g. for size 100×70 = 0.030mm.
74-00881

Automatic blocking of the ribbon during stretching.
Rewinding the ribbon by pressing the button.
Mobile terminal hook.
Yellow tape measure, printed black / red, acrylic coating for better resistance to abrasion.
Case dimensions: 52x49x22mm
Ribbon length: 2m
Band width: 13mm
74-00882

Pure black Chinese bristle, 90 % tops. Metal ferrule, 9. gauge, unpainted wooden handle.

Of stainless spring steel strip.
Clean electrolytically applied black graduations and figures with a smooth surface. Easy to read. Rounded edges to prevent injuries.
Upper and lower edges both with 1 mm graduations.
74-00877

Of stainless spring steel strip.
Clean electrolytically applied black graduations and figures with a smooth surface. Easy to read. Rounded edges to prevent injuries.
Upper and lower edges both with 1 mm graduations.
74-00878

Of stainless spring steel strip.
Clean electrolytically applied black graduations and figures with a smooth surface. Easy to read. Rounded edges to prevent injuries.
Upper and lower edges both with 1 mm graduations.

Of special stainless clock spring steel with ground measuring edges. Wide version. Upper and lower edges both with mm graduations. Very easy to read due to matt surface and sharp graduation scale.
Graduations electrolytically etched. Matt non-reflective surface.

Made of flat-oval steel, hardened and tempered. Blade uniformly through hardened; can be repeatedly reground without re-hardening. Head specially annealed to prevent splintering.

Made of flat-oval steel, hardened and tempered. Blade uniformly through hardened; can be repeatedly reground without re-hardening. Head specially annealed to prevent splintering.

The casting table has been designed to meet the needs of all kind of prothetic patients, including lower extremity prostheses, hip and knee disarticulation prostheses.
The geared system and the ergonomic design enable the technician to adjust the height appropriately allowing the patient to comfortably stand upright while the measurements are taken.

With roll-about tray, 220V-380V / 20kW / 50Hz, working height: 1800x1600x400mm
External dimensions: 2000x1700x500mm

• Supply voltage: 230V, 50Hz
• 1 sheet
• Useful surface 36 x 43 cm
• Dimensions 39.5 x 51 x 11 cm
• Number of tubes 1

Vacuum-press for manufacturing of insoles and foot-orthotics. Without vacuum pump

Type: Vacuum-press , Bench-top version for use with external vacuum-supply
Frame Dim. (LxW): 520 x 350mm, gas-shock supported, frame tension adjustable (equipped with Soft-bladder)
Vacuum-Pump: none
Power supply: 230V / 50Hz
W 360 x D 650 x H 250 mm
Weight 21 kgs

Vacuum-press for pairwise manufacturing of insoles and foot-orthotics. With vaccum pump

Type: Vacuum-press , Bench-top version
Frame Dim. (LxW): 520 x 350mm, gas-shock supported, frame tension adjustable
(equipped with Soft-bladder)
Vacuum-Pump: Rotary vane, oil- and maintenance-free, 6 m/h / 200mbar, vacuum-automatic controlled
Power supply: 230V / 50Hz
W 360 x D 650 x H 250 mm W 360 x D 650 x H 250 mm
Weight: 30 kgs

Packaged in a blue plastic box with pilot drills
Content :
1 set of HSS hand taps each:
DIN 352 M 3 / 4 / 5 / 6 / 8 / 10 / 12
1 HSS die of each DIN 223:
M3 / 4 / 5 / 6 / 8 / 10 / 12
HSS twist drills, DIN 338 N, ground:
Ø2.5 / 3.3 / 4.2 / 5.0 / 6.8 / 8.5 / 10.2mm
1 die holder DIN 225:
20x5 / 20x7 / 25x9 / 30x11 / 38x14
1 left hand wrench DIN 1814:
Group 1 + 2
74-01202

74-01752

permanently elastic thermoforming film, moulding temp: 120-135 °C / 248-275 °F

permanently elastic thermoforming film, moulding temp: 120-135 °C / 248-275 °F
