High performance blades with maximum cutting capacity and long life

Entirely made of steel, unbreakable. Foldable form with self-closing coupling hooks

Material:
- cork-compact sheets

Application:
- for insoles and embeddings
- for height adjustments, shoe last modifications and volume adjustments of prosthetic sockets

Characteristics:
- light-weight
- bendable
- well grindable
- bonds well with contact glues

Sturdy shears body of quenched and tempered steel. Moving blade guides free of play (with low friction losses), blades of special tool steel, specially hardened and ground. Lever arm with counterweight spring for protection in the event of accidents, all pivot pins adjustable, all models with steplessly adjustable clamping arm.
With compound action. Cuts sheet metals and round steel bar.
-The following specifications are required for subsequent orders of spare blades: Make, model, and, if known, the machine number or accurate scale drawing.
-Please note: The indicated cutting performance is a maximum. If sustained use at the maximum cutting performance is required, we recommend the next larger model.
-Cutting performance specifications refer to materials of 450 N/mm2 tensile strength.
Cutting capacity sheet thickness: up to 5 mm
Cutting capacity round steel bar ⌀: up to 11 mm
Upper blade length: 173 mm
Lower blade length: 150 mm
74-00709

Strong base with lapped standing surface. Reading 0.02 mm with fine adjustment. The scriber is carbide tipped. With adjustable measuring beam, magnifying glass and locking screw.
Metrology: Analogue / Material: Stainless steel, INOX / Surface base, Length: 135 mm / Tracing height: 300 mm / Vernier: 1/50 mm / Calibration: E1 / Base area, width: 90 mm / Rule section: 28 × 9 mm / Allowable error: 0.06 mm

Precision machined edges and flat surfaces

Disposition of the blades around the axis of the tool

Disposition of the blades around the axis of the tool

Bi-metal hole saw set with popular hole saw diameters. HSS variable tooth pitch for smooth cutting and long service life.
Impact-resistant plastic box with bi-metal hole saws, mounting shanks and centre drills.
Technical Data
Hole saw ⌀: 22; 30; 35; 44; 51; 68 mm
Number of pieces: 10
Number of mounting shafts: 2
Number of centre drills: 2

With sharp drill point, pre-drilling not necessary. Conically increasing cutting edges and radially relief ground circumference for a paring cut. With scale in the flutes. Three drive flats on the shank.
Leaves no burr or chatter marks.
Sheet metal 0.1 − 2 mm, stainless steel 0.1 − 1 mm, non-ferrous metals: 0.1 − 5 mm, plastics up to 10 mm.
Cutter ⌀ Dc: 16 mm - 30.5 mm
Overall length: 71 mm
Shank ⌀: 10 mm
Tool material: HSS

Center drill with radius type R

With shock-proof plastic handle and round chrome-plated blade.
Material: Chrome vanadium steel.
Blade length: 80 mm
Blade ⌀: 5 mm
overall length: 155 mm

2-part plastic handle with spring-loaded lock for locking / unlocking blades / telescopic shank. Blades can be stored in the removable end cap.
74-00874

Matte chromed anti-glare reading parts.
Fine graduation, high contrast.
Finely honed measuring surfaces.
Locking screw at the top.
Technical data
All parts: hardened / Depth gauge: flat / Metrology: analog / Locking: Locking screw on top / Thread table: Caliper table / Material: Stainless steel, INOX / Switchable reading: mm - inch / Graduation: 1/20 mm / Graduation: 1/128 inch / Allowable error: 0.05 mm / Standard: DIN 862 / Measuring range: 0 mm - 150 mm / Calibration: A1 / Packing: Case / Reading: 0.05 mm / Spout length: 40 mm
74-01749

Beveled measuring tips for measurements at the bottom of the thread and in narrow grooves. Rounded nose tips for interior measurements. Graduation with high contrast. With stop screw. Fully tempered to ref. 300, tempered measuring surfaces from ref. 500.
Material: Stainless steel, INOX / Metrology: Analog / Vernier graduation: mm / inches / Packing: Robust box / Graduation: 1/20 mm / Graduation: 1/128 inch / Locking: Locking screw on top / Switchable reading: mm / inch / Measuring range: 0 mm - 300 mm / Spout length: 90mm / Calibration: A1 / ⌀ Internal measuring shoulder: 10 mm / Standard: DIN 862 / Permissible error: 0.05 mm
74-00887

Sturdy design with long arms, made of tool steel. Points and measuring faces ground and hardened. Solid spindle with adjusting nut for quick and fine adjustment. Annular spring provides constant spring tension.
With replaceable tips.

Boîtier en plastique avec clip-ceinture amovible. Rembobinage automatique amorti et blocage du ruban. Crochet terminal mobile, CRM 391
74-00882

Of special stainless clock spring steel with ground measuring edges. Wide version. Upper and lower edges both with mm graduations. Very easy to read due to matt surface and sharp graduation scale.
Graduations electrolytically etched. Matt non-reflective surface.

With hardened jaws and steel handles. Possibility of removing a handle to allow use in confined spaces.
Reinforced model. All dimensions with high quality forged steel body and solid steel handles.
□ capacity: 3 mm - 9 mm
For hand taps DIN 352: M4 - M12
For ⌀ hand reamers DIN 206: 5 mm - 10 mm
Total length: 280 mm

Unscrewable steel handles. With 5 clamping screws for fixing the die. Up to ref. 65 × 25 in die-cast zinc, from item no. 75 × 20 in steel.
For ⌀ die: 25mm
Height: 9mm
Standard: EN 22568
Total length: 210mm
74-01736

Unscrewable steel handles. With 5 clamping screws for fixing the die. Up to ref. 65 × 25 in die-cast zinc, from item no. 75 × 20 in steel.
For ⌀ die: 20mm
Height: 5mm
Total length: 175mm
74-01734

Closed, pre-stretched line. ≥ M3 with GUN entry on both sides for easy threading and clean chip evacuation in the cutting direction. Entry on 2 nets. Ground and nitrided, rake angle approx. 15 °.
Thread size: M8
Thread Type: M
Side angle: 60 °
Tool type: HSS E
Tolerance class: DIN 13 6g
Cutting direction: straight
Pitch: 1.25mm
⌀ outer: 25mm
Height: 9mm

Closed, pre-stretched line. ≥ M3 with GUN entry on both sides for easy threading and clean chip evacuation in the cutting direction. Entry on 2 nets. Ground and nitrided, rake angle approx. 15 °.
Thread Size: M4
Thread Type: M
Side angle: 60 °
Tool type: HSS E
Tolerance class: DIN 13 6g
Cutting direction: straight
Pitch: 0.7mm
⌀ outer: 20mm
Height: 5mm

Closed, pre-stretched line. ≥ M3 with GUN entry on both sides for easy threading and clean chip evacuation in the cutting direction. Entry on 2 nets. Ground and nitrided, rake angle approx. 15 °.
Thread size: M10
Thread Type: M
Side angle: 60 °
Tool type: HSS E
Tolerance class: DIN 13 6g
Cutting direction: straight
Pitch: 1.5mm
⌀ outer: 30mm
Height: 11mm

Jeu de 3 tarauds composé d’un ébaucheur, d’un intermédiaire et d’un finisseur

Special grade for: Stainless steel

Special grade for: Stainless steel

Special grade for: Stainless steel

Special grade for: Stainless steel

2-component holder (up to size 3-20) with pistol handle with exchangeable precision ground punch cutters. For the production of gaskets two punch cutters of different ⌀ are inserted together in the holder.
For punching or manufacturing discs / rings in one operation. For rubber, leather, felt, plastic, cork, fabric or similar materials.
1 each circle cutter ⌀: 55−330 mm
Centring point No. 832140: 1 pc.
1× each punching tool ⌀ No. 832110: 15 pcs.
size 3; 4; 6; 8; 10; 12; 14; 16; 18; 20; 22; 24; 26; 28; 30
Available combinations of punches inner : outer (mm): 3−10 inner with 12−30 outer 12−20 inner with 22−30 outer
Container length×width×height (mm): Plastic 275×205×50
Use an underlay of wood, leather etc. when punching to avoid damage.
The following combinations are not possible: 20 (inner) with 22 (outer); 30 (inner) with 32 (outer); 40 (inner) with 42 (outer); 50 (inner) with 52 (outer).

2-component holder (up to size 3-20) with pistol handle with exchangeable precision ground punch cutters. For the production of gaskets two punch cutters of different ⌀ are inserted together in the holder.
For punching or manufacturing discs / rings in one operation. For rubber, leather, felt, plastic, cork, fabric or similar materials.
1× each punching tool ⌀: 10 pcs.
size 3; 4; 6; 8; 10; 12; 14; 16; 18; 20
Available combinations of punches inner : outer (mm): 3−10 inner with 12−20 outer
Container length×width×height (mm): Plastic 140×100×40
Use an underlay of wood, leather etc. when punching to avoid damage.
The following combinations are not possible: 20 (inner) with 22 (outer); 30 (inner) with 32 (outer); 40 (inner) with 42 (outer); 50 (inner) with 52 (outer).

Strong, forged design, special tough varnish; taper section (cutting part) bright metal. Slight internal taper for releasing the cut pieces.
74-01717, 74-01718, 74-01719, 74-01720, 74-01721, 74-01722, 74-01723, 74-01724

Octagonal body, uncoated head

Clés dynamométriques à un bras sans vernier de réglage. Réglables par un appareil de contrôle de clé dynamométrique

Forged by stamping. With opening to tight tolerances

Hacksaw frame with all-steel back. Alternative blade setting at 90° for flush cutting. Plastic handle. Overall length 520 mm.
The bow saw with its prominent bow frame is characterised by the u-shaped bow which tensions the saw blades. The limitation in depth of cut of hand bow saws is presented by the distance from the blade to the bow. This frame shape permits the use of particularly slim saw blades, which in other frame shapes would be liable to buckle when subjected to cutting movements with the force in alternate senses or other than in the pulling sense. Thanks to the thin hacksaw blades the metal cutting effort required is reduced, because of the small cutting width. Thus this type of saw is the classic standard for hacksaw work in metalworking.
74-01200

Universal hand files 4 in 1 with a flat side and a semi-round side, with two sizes each

Keyed files are manufactured on precision automatic machines. They guarantee high performance and a long service life.

The blanks are forged and ground; manufactured with an exact cut of even density and depth using special machines. These non-convex files have tooth profiles appropriate to each grade of file.
Cuts on all faces; convex end.
The quality file for workshop use with long tool life and high removal rate.
Standard: DIN 7261 form C
Length without tang: 250 mm
Width: 18 mm
74-01701

The blanks are forged and ground; manufactured with an exact cut of even density and depth using special machines. These non-convex files have tooth profiles appropriate to each grade of file.
With helical cut; convex end.
The quality file for workshop use with long tool life and high removal rate.
Standard: DIN 7261 form F
Diameter: 9.2 mm
Length without tang: 250 mm

The blanks are forged and ground; manufactured with an exact cut of even density and depth using special machines. These non-convex files have tooth profiles appropriate to each grade of file.
With helical cut; convex end.
The quality file for workshop use with long tool life and high removal rate.
Standard: DIN 7261 form E
Length without tang: 200 mm

The blanks are forged and ground; manufactured with an exact cut of even density and depth using special machines. These non-convex files have tooth profiles appropriate to each grade of file.
Cuts on 3 faces; square end.
The quality file for workshop use with long tool life and high removal rate.
Standard: DIN 7261 form A
Length without tang: 200 mm

Heavy-duty head with additionally induction hardened cutting edges (approx. 64 HRC). Laid-on joint. High cutting performance due to optimum leverage.
Jaws bright finished, plastic coated handles.
For all types of wire (long working life even with hard wire). Heavy duty for the most demanding applications.
Standard: DIN ISO 5749
Material: Chrome vanadium steel, drop-forged and oil-hardened.
Cutting capacity piano wire up to ⌀2 mm
Cutting capacity soft wire up to ⌀3.4 mm
overall length: 160 mm
Cutting capacity hard wire up to ⌀2.5 mm
ETOOPLIESC160

Very long snipe nose jaws. Cutting edges induction hardened (approx. 61 HRC), suitable for hard and soft wire. Serrated inside jaws.
Pliers bright finished, plastic coated handles.
Standard: DIN ISO 5745
Material: Chrome vanadium steel, drop-forged and oil-hardened.
overall length: 200 mm
Jaw length: 73 mm
Jaw design: snipe-nosed, straight
Jaw characteristics: Cutting edges induction hardened (approx. 60 HRC)
Type of jaws: inner face roughened
Handle: plastic coated
Material: Chrome vanadium steel, drop-forged and oil hardened
Surface: bright finish
ETOOPLIELN200
74-00779

Universal cutting disc for steel and INOX, good cutting quality and resistant.
For freehand cutting on electric and pneumatic angle grinders with a maximum cutting speed vc of 80 m / s.
Maximum rotation speed: 80 m / s
⌀ bore: 22,23 mm
⌀ disc: 230 mm
Disc thickness: 2.5 mm
Max rotation speed: 6 600 min-1

Solid polishing pastes in homogeneous blocks, easy cleaning after use

also referenced under: OOMAMARP3000K, CRM 100

Corrugated wire securely crimped into the steel body. Dense packing, high concentricity and wear resistance

also referenced under: OOMAMARP3000G, CRM 96
