nickel plated

nickel plated

4 x 6
4 x 8
4 x 12

Material:
- EVA cork-scrap sheets

Application:
- for insoles and embeddings
- for shoe last modifications

Characteristics:
- light-weight
- thermoplastic (mouldable at approx. 130 °C)
- high density
- approx. 60 Shore A
- bonds well with contact glues

Material:
- cork-compact sheets

Application:
- for insoles and embeddings
- for height adjustments, shoe last modifications and volume adjustments of prosthetic sockets

Characteristics:
- light-weight
- bendable
- well grindable
- bonds well with contact glues

Material:
- cork-compact sheets

Application:
- for insoles and embeddings
- for height adjustments, shoe last modifications and volume adjustments of prosthetic sockets

Characteristics:
- light-weight
- bendable
- well grindable
- bonds well with contact glues

Material:
- cork-compact sheets

Application:
- for insoles and embeddings
- for height adjustments, shoe last modifications and volume adjustments of prosthetic sockets

Characteristics:
- light-weight
- bendable
- well grindable
- bonds well with contact glues

1000x1000x25mm, 15-18 Shore A

1000x1000x20mm, 15-18 Shore A

1000x1000x12mm, 15-18 Shore A

1000x1000x12mm, 15-18 Shore A

1000x1000x3mm, 15-18 Shore A

1000x1000x6mm, 15-18 Shore A

1000x1000x5mm, 15-18 Shore A

1000x1000x4mm
cell-polyethylene foam
Application:
-for padding of positioning splints and correctional braces (e.g. orthoses)
Characteristics:
-closed-celled expanded PE
-washable
-suitable for processing with Streifylen and Streifycolor
-molding temperature depending on heat source -approx.100-130 °C
-approx. 15-18 Shore A

1000x1000x3mm, 15-18 Shore A

1000x1000x3mm, 15-18 Shore A

2.5x1740x960mm

3x1740x960mm
Polyethylene foam material, thermo-moldable at approx. 110-130°C, approx. 30° Shore A

2x1740x960mm
Polyethylene foam material, thermo-moldable at approx. 110-130°C, approx. 30° Shore A

thermo-moldable at approx. 90 - 130°C., approx. 35° Shore A, 1030x1035x10mm

thermo-moldable at approx. 90 - 130°C., approx. 35° Shore A, 1030x1035x2mm

5x1100x1100mm
Polyethylene foam material, thermo-moldable at approx. 110-130°C, approx. 30° Shore A

6x1100x1100mm
Polyethylene foam material, thermo-moldable at approx. 110-130°C, approx. 30° Shore A

3x1000x1000mm
Polyethylene foam material, thermo-moldable at approx. 110-130°C, approx. 30° Shore A

6x2000x1000mm
Polypropylene copopolymer (PPC), Excellent thermoforming, Chemical and corrosion resistant, thermo-moldable at approx. 165°C, approx. 75° Shore D

Plastic acrylic resin (non-toxic), pigment dye. Clean tools with water. High hardness, low shrinkage. Protective varnish for the exterior. Practical working time 20 to 30 min. Setting time 45 to 60 min. Dosage 2 for 1, 100 g / 50 g, variable depending on the application. Consumption 200 to 300 ml per m². Realization of decorative or technical elements by molding, laminating or projection. Interior and exterior decor panel. Application in casting or in lamination with fabric + fiberglass reinforcement. Direct molding on polystyrene / bodywork. Clean use, non-toxic, durable over time, low water permeability. Supplied with: 1 Part B bottle.
Dry milk-white color.

Content:
Urethane Bonding Component A
Urethane Bonding Component B
Chopart PU, Set Small Parts
V.A. Chopart Sohlen/Bonding Kit
Primer for Chopart Bonding

The 3M spray adhesive is versatile and ideal for the reliable, clean and fast bonding of large areas. It is ideal for optimizing complex production processes and simplifying everyday work in almost all craft and industrial sectors. It is also suitable for everyday use at home. It eliminates the need for brushes, spray guns and other tools. The spray adhesive is free from silicone and chlorinated solvents. The optimal spray distance is 30 cm

These sealants replace hemp, sealing tapes, and pastes, they are resistant to gases, liquids, air, water, oils, hydrocarbons and many chemical products. Complete surface contact ensures a 100% seal. Unscrewing, or correction of position during assembly can be performed using conventional tools at any time before the sealant hardens. No sealant residues to block filters and valves.
The stick with pasty sealant is economical in consumption, no drips after use.
Application:
Improved bonding of suckers.
Note:
Before applying sealant, clean the threads with general-purpose cleaner
Labelling of hazardous substances: GHS07 Caution
Content of stick: 19 g
Colour of sealant: orange
minimum break-away torque: 5.8 N·m
Temperature range: -55 °C - 150 °C
for thread size M to: M80
for imperial thread size: 3 inch
Strength for disassembly: low
fluorescent:no

When sprayed, the Teflon ™ / PTFE microparticles ensure clean dry lubrication without oil-covered hands, adhesive protection and effective reduction of static, dynamic and rolling friction.
Dry lubrication and hygienic solid.
No adhesion of dirt and dust on the treated surface.
No formation of annoying lubricant residues.
Oil and fat free.
Hygienic, clean and ecological.
Durable and resistant lubrication and sliding effect.
Resin-free, non-hardening.
High material compatibility (all metal and plastic parts!).
Silicone and acid free.
Execution: Aerosol can
Content: 0.4 l
Color: transparent
Boiling point: 78 ° C
Flash point: -104 ° C
Auto-ignition temperature: 400 ° C
Water solubility: insoluble
Signaling of hazardous substances: SGH02 Flammable
Class of dangerous goods: 2.1
UN number: UN1950

Color white-transparent, water and oil resistant, resistance to the action of most chemicals, NLGI consistency class 2-3, -40 ° C - + 200 ° C, non-toxic.
For lubrication between metal and plastic or metal and elastomer, lubricating grease for valves, O-rings and ball valves

Color white-transparent, water and oil resistant, resistance to the action of most chemicals, NLGI consistency class 2-3, -40 ° C - + 200 ° C, non-toxic.
For lubrication between metal and plastic or metal and elastomer, lubricating grease for valves, O-rings and ball valves

To lighten resins and save material

The use of thread lockers prevents unintentional detachment and loosening of screw connections. One-component anaerobic adhesives are suitable for all types and shapes of threads. The screw connections are sealed. Reliably prevent slipping.
Liquid thread lock.
Weak tightening - Loosening possible with a normal tool.
Medium tightening - Loosening still possible with a normal tool.
Very strong tightening - Loosening only possible with a special tool or by heating (> 150 ° C).
Medium resistance, serves as a thread lock while ensuring tightness.
Manufacturer no .: 243
Chemical basis: Dimethacrylate ester
Dynamic viscosity: 1'300 mPa · s - 3'000 mPa · s
Density: 1.15 g / cm³
Flash point: 93 ° C
Temperature range: -55 ° C - 180 ° C
Maneuverability after: 10 min
Usable after: 2 h
Property: thixotropic; fluorescent under UV light; waterproof; oil resistant; vibration resistant; prevents seizure
for material: Metal
for applications: Threadlockers; Grouting; Universal use
For thread sizes M up to: M36
Resistance class: Medium
Minimum initial breakaway torque: 26 N m
Disassembly: with normal tool
Blue color
Capacity: 50 ml
Storage temperature: 8 ° C - 21 ° C
Shelf life from date of manufacture: 24 mo
Hazardous Substance Markings: SGH07 Warning; SGH09 Environmental hazard
Dangerous goods class: 9
UN number: UN3082

The use of thread lockers prevents unintentional detachment and loosening of screw connections. One-component anaerobic adhesives are suitable for all types and shapes of threads. The screw connections are sealed. Reliably prevent slipping.
Liquid thread lock.
Use:
Weak tightening - Loosening possible with a normal tool.
Medium tightening - Loosening still possible with a normal tool.
Very strong tightening - Loosening only possible with a special tool or by heating (> 150 ° C).
For small screws up to M6 and for subsequent screw locking.
Manufacturer no .: 290
Chemical basis: Dimethacrylate ester
Dynamic viscosity: 20 mPa s - 55 mPa s
Density: 1.07 g / cm³
Flash point: 93.3 ° C
Temperature range: -55 ° C - 150 ° C
Maneuverability after: 20 min
Usable after: 3 h
Property: High capillarity; fluorescent under UV light; waterproof; oil resistant; vibration resistant; prevents seizure
for material: Metal
for applications: Threadlockers; Grouting; Porosity of weld seams; Porosity of cast iron and sintered metal parts; Pre-assembled screw connections
For thread sizes M up to: M6
Resistance class: Medium
Minimum initial breakaway torque: 10 N m
Disassembly: only by heating
Green color
Capacity: 50 ml
Storage temperature: 8 ° C - 21 ° C
Shelf life from date of manufacture: 29 mo
Hazardous substances marking: SGH07 Warning

High strength, dimethacrylate ester-based retaining compound with medium cure speed and low viscosity; suitable for filling small gaps.LOCTITE® 601 is a green, anaerobic, low viscosity, medium cure speed, dimethacrylate ester-based retaining compound suitable for a max. diametrical clearance of 0.1 mm. It is a high strength product for applications that require a permanent bond. Fixture time on steel is 25 min and service temperature from -55ºC to +150ºC. Fluorescence allows product presence to be monitored.

1-part product, requires no mixing
Medium cure speed
High strength for permanent bonds
Low viscosity, small gap filling
Fluoresces for presence monitoring

Universal use for joining various materials. Fast hardening and clean, almost invisible assemblies. Cures under the effect of ambient humidity.
Universal quick glue for almost the majority of materials, such as plastics, elastomers, metals, ideal for paper, cardboard, wood, leather and fabrics.
Manufacturer no .: 401
Chemical basis: Ethyl cyanoacrylate
Dynamic viscosity: 70 mPa s - 110 mPa s
Density: 1.05 g / m3
Form: liquid
Temperature range: -40 ° C
Maneuverability after: 5 s - 10 s
for material: Fabric; Wood; Plastic; Leather; Metal; Paper; Elastomers; Glass
Maximum deviation: 0.15 mm
Tensile and shear strength: 20 N / mm²
Color: transparent
Capacity: 20 ml
Storage temperature: 2 ° C
Shelf life from date of manufacture: 24 mo
Hazardous substances marking: SGH07 Warning
Dangerous goods class: 9
UN number: UN3334

UNIVERSAL WRIST
BRAND: ORTHOPUS
Materials: stainless steel + aluminium
Weight: 93g (with tool holder)
Sizes: Ø53x18 mm
Made in France
NB: TO HAVE A COMPLETE AND FUNCTIONAL WRIST, IT IS NECESSARY TO BE EQUIPPED WITH THE WRIST AND THE TOOL HOLDER (REF 80 P 20.HW) AS ON THE SECOND PICTURE

Adapted to upper-limb amputations including disarticulation of the wrist, this mechanical wrist fits directly into a socket and connects quickly to a large number of tools. The universal wrist is equipped with two levers to connect and disconnect a tool, or to lock (prono-supination) rotation as required.

BRAND: ORTHOPUS
Material: stainless steel
Dimensions: Ø53
Weight: 40.8g
Thread: M10
Made in France
It allows you to use all kinds of tools for everyday life by quickly attaching them to the universal wrist (REF 80 P 20.W).

With pneumatic door
Temperature: 60° to 250°
50-60Hz, 850W
Dimensions outside: 1640x1134x1756mm
Working area: 1828x1828mm

200gr/m2, 2x2 twill
Carbon fibers are very strong · Light weight · Reduced elongation at break · Very resistant to temperature variations. This fabric is much stronger than most metals or other fiberglass reinforced materials. This fabric is elastic, very resistant and attenuates vibrations. · The material to the aeronautical standard makes it possible to manufacture fine agglomerates but with high resistance.

- Robust and sturdy three-wheel active wheelchair with a large rubber caster wheel, large 26” (66 cm) rear wheels, and a long wheelbase that allows for safe and stable mobility over uneven ground
- Provides a range of adjustable features to ensure optimal fitting and comfort
- Intended for use outdoors and for limited use indoors; suitable for use in rugged conditions and on uneven surfaces
- The length and weight of this wheelchair limits its ability to be transported easily
- Each chair comes with a foam pressure relief cushion, basic tool kit, and tire repair kit
- The Rough Terrain can be converted into a tricycle by attaching Motivation’s Clip-on Tricycle.
- Intended for active adult users, older adults (over 65 years old), and teenagers/older children who use the wheelchair as their primary method of mobility and do not require postural support that exceeds the support features of the Motivation Rough Terrain wheelchair
